SKU: CH-SYSCategories: Radio Remote Control Systems

INMOTION Classic Radio Remote Control System

1 customer review

$509.00$1,369.00

The INMOTION Classic Radio Control System is economical and easy to use. Options come for 1, 2, 3, 4, or 5 motion control and 1 or 2 speed.

Save when you buy 2+ Classic Radio Systems! You can mix and match different configurations. All configurations are in stock and ship within 24 hours from our warehouse in Nappanee, Indiana.
Save 5% on orders of 2 or more.
Save 10% on orders of 10 or more.

The INMOTION Classic Radio Control System

The INMOTION Classic Radio Control System is suitable for complex industrial applications. The Classic Radio Control embodies simplicity with its crystal-based configuration.

Durable

If you work around dust or water, the INMOTION Classic Radio Control System is the right choice for you. The IP65 rated fiberglass enclosure enables you to use this system anywhere. It’s designed to withstand high vibrations from heavy-duty mobile and light-duty industrial equipment.

Energy Efficient

The INMOTION Classic Radio Control System will also save you time and money. It has 2 AA batteries that last up to 3 months. As a result, you will spend less time swapping batteries and spend more time getting things done.

Versatile

You will have the mobility to get your job done with the Classic Radio Control. This system has an operating range of up to 300 feet. You’ll get to work with larger applications without compromising safety and connectivity.

Features

  • Safety Emergency Off (E-Stop) and Start Key Switch
  • Low Power Consumption
  • 300 Feet Line of Sight Nominal Operating Distance
  • Advanced RF with Over 4.1 Billion ID Codes
  • Shock Resistant Mounting Feet
  • Ideal for Mobile and Light-Duty Industrial Equipment

Configurations

You can quickly and easily configure your Classic Radio Control to meet your needs.

All of the button configurations can be ordered with one speed or with a slow and fast speed (2 speed).

The 2 Button Classic Radio has a single function (or motion). Used to move a monorail hoist up/down.

The 4 button Classic Radio is for two functions (or motions). Used to move a motorized trolley along a monorail and a hoist up/down.

The 6 button Classic Radio is for three functions (or motions). Used to control motorized end trucks, move a motorized trolley along a bridge, and to move a hoist up and down.

Upgrades

Looking to increase the functionality of a new 3 motion, 2 speed radio remote system?

Upgrade so you can operate two different hoists on the same system independently or at the same time. Get enhanced safety by installing a horn in the receiver. That way your radio remote system will sound whenever you are operating.

Included in the Box

Each INMOTION Classic Radio Control System includes:

  • One receiving unit
  • Two transmitters with lanyards and button covers
  • Batteries
  • Mounting hardware
  • Installation instructions

Looking for a replacement transmitter or remote?

Hoist Zone sells replacement transmitters and remotes for all INMOTION radio control systems.

InMotion Classic Transmitter Specs

Frequency 310 MHz
Modulation Method 4 FSK
Typical Operating Range 300 ft. (100M)
Power Supply 2 X 1.5V “AA” Battery
Average Power Consumption 10mA (220–260)40mA (310–532)
Operating Temperature -49F to + 176F
Protection Degree IP65
Housing Material Fiberglass / ABS
Overall Dimension 6.4 x 1.9 x 1.8 Inches

InMotion Classic Receiving Unit Specs

Frequency 310 MHz
Control System Crystal
Power Supply 110~120 VAC (Standard)12/24 VDC (Optional)
Operating Temperature -40F to + 149F
Protection Degree IP65
Housing Material Fiberglass / ABS
Overall Dimensions 6.34 x 2.91 x 2.05 Inches (220–260)6.57 x 6.06 x 3.46 Inches (310–532)
Installation and Mounting Four Bolts (220–260)Single Bolt (310–532)

Weight 5.8 lbs
Dimensions 12 × 10.75 × 3.75 in
Brand

Buttons

2 Buttons, 4 Buttons, 6 Buttons, 8 Buttons

Country of Origin

Import

Motion

1 Motion, 2 Motion, 3 Motion, 4 Motion, 5 Motion

Warranty

1 Year Warranty

Voltage

DC 12-24V, Standard 110V

Series

InMotion Classic

  1. Harold

    We have used two Inmotion Classic Radio Remote Control systems for 2 years and are very satisfied with them. Easy to install and reliable. We use them in a high production environment where the hoists are a vital part of the process. Just purchased our third system.

Add a review

Your email address will not be published. Required fields are marked *

Frequently Asked Questions

What does "step" mean?

“Step” is the term used to refer to the number of different lifting speeds a hoist has. Sometimes the term “speed” is used instead of “step.” A single step (or single speed) hoist can only lift at the speed that it was originally programmed. A two step (or two speed) hoist can be programmed to lift at a slower speed and faster speed. A variable speed hoist has a lift speed that can be adjusted on the fly by the hoist operator with only the twist of a knob.

What does "motion" mean?

“Motion” is the term used to refer to how many different components a radio can control. A 1 motion radio is used to control a hoist. A 2 motion radio is used to control a hoist and trolley. A 3 motion radio is used to control a hoist, trolley, and a bridge. Radios with 4 or more motions are for more advanced applications where the operator wants control multiple hoists, trolleys, or bridges all at the same time.
